size | standard Rim | Section Width(mm) | Overall Diamater(mm) | Max Load (kga) | Pressure (kpa) |
28L-26 | DW25 | 715 | 1615 | 3460 | 170 |
23.1-26 | DW20 | 587 | 1660 | 5055 | 200 |
18.4-38 | W16 | 467 | 1888 | 3200 | 210 |
18.4-34 | W16 | 467 | 1755 | 3000 | 210 |
18.4-30 | W16 | 430 | 1670 | 2605 | 180 |
16.9-34 | W15 | 430 | 1670 | 2605 | 200 |
14.9-30 | W13 | 398 | 1560 | 2190 | 230 |
14.9-26 | W13 | 378 | 1400 | 1820 | 180 |
14.9-24 | W13 | 378 | 1265 | 1760 | 180 |
13.6-38 | W12 | 345 | 1710 | 2675 | 230 |
12.4-28 | W11 | 315 | 1260 | 1510 | 230 |
Brand | Ruijide |
Condition | New |
3 year Warranty | |
Applicable Industries | agricultural Energy & Mining |
Machinery Test Report | Provided |
Marketing Type | Ordinary Product |
Type | Other |
Use | Agriculture |
Place of Origin | Xinjiang, China |
Raw material | Rubber from MALAYSIA,STEEL CORD FROM BEKAERT |
Technology | German Technology |
Series | Full range from 12-51inch |
Series: Full range from 12-51inch Rubber content | 55% |
Size | PR | Standard Rim | Load capacity (kg) | Pressure (kpa) | Tyre Inflated Dimension(mm) | ||
Section Width | Overall Diameter | ||||||
400-8 | 4 | 3.00D | 225 | 250 | 110 | 435 | |
400-12 | 4 | 3.00D | 265 | 240 | 112 | 535 | |
400-14 | 4 | 3.00D | 270 | 340 | 110 | 590 | |
400-16 | 4 | 3.00D | 300 | 340 | 110 | 640 | |
500-12 | 4 | 4.00E | 280 | 200 | 145 | 590 | |
550-17 | 4 | 4.50E | 400 | 250 | 150 | 720 | |
600-12 | 6 | 4.50E | 405 | 180 | 165 | 640 | |
600-14 | 6 | 4.50E | 515 | 250 | 165 | 690 | |
600-16 | 6 | 4.50E | 495 | 250 | 165 | 745 | |
650-16 | 6 | 4.50E | 495 | 250 | 180 | 765 | |
750-16 | 6 | 5.50F | 650 | 210 | 205 | 810 | |
750-20 | 6 | 5.50F | 760 | 210 | 205 | 910 | |
8.3-20 | 6 | W7 | 695 | 240 | 210 | 895 | |
8.3-24 | 6 | W7 | 810 | 240 | 210 | 995 | |
9.5-16 | 8 | W8 | 900 | 325 | 250 | 860 | |
9.5-20 | 8 | W8 | 955 | 210 | 240 | 950 | |
9.5-24 | 8 | W8 | 1110 | 210 | 240 | 1050 | |
9.5-32 | 8 | W8 | 1260 | 280 | 240 | 1250 |
